MOTOR MANUFACTURER · Jiangsu, CHINA

Zhongyi Gear Motors

Zhongyi publishes dedicated parking-equipment drives and a separate JYK helical-bevel range. A garage lift is a controlled motion and holding problem; a general right-angle conveyor drive is a torque, ratio and shaft-load problem. Start with the machine task before choosing a housing code.

LocationJiangsu, China
Published catalogue1 product series
Motor families1 represented

LIANSHUI · PARKING AND RIGHT-ANGLE DRIVES

Huai’an Zhongyi: specify the parking-lift drive, not just a gear ratio

Explore the published range ↓

01 / APPLICATION ROUTES

Parking lifts and production lines need different proof

A parking lift needs motion, stopping and holding as a system

Zhongyi has a separate catalogue for multi-level parking equipment. One JNAP-50DX entry is titled 3 HP (2.2 kW) and discusses a compact housing and brake, but the surrounding page repeats marketing text and does not provide a complete, legible duty or brake test table. That title cannot establish a safe payload, number of starts per hour, stopping distance or holding capacity for a garage installation. Specify the complete lift mechanism and independent safety devices before choosing a drive.

Confirm before ordering Give platform mass, counterweight and travel, lift speed, starts per hour, acceleration/deceleration, mains supply, brake-release and stop sequence, existing gearbox drawing, output shaft load and required holding test. Request a current configuration-specific brake and gearbox data sheet plus system commissioning plan.

A right-angle line drive starts at the output shaft

The manufacturer's JYK listings cover helical-bevel right-angle gearmotors, with housing references from JYK37 through JYK157. The catalogue describes foot, hollow-shaft, flange and torque-arm mounting alternatives. For a packaging or material-handling line, selecting a ratio without radial/axial loading, service factor and installation orientation risks an undersized output stage even when motor power looks adequate.

Confirm before ordering Specify required output rpm and running/peak torque, start frequency, shock factor, radial/axial shaft loads, mounting face and orientation, available motor supply, ambient, lubricant/service plan and dimensional envelope. Ask for the precise JYK size and gear-stage arrangement rather than a family name.

02 / CATALOGUE LIMITS

Do not assemble a fictional drive from family maxima

The published range is shared across many configurations

The JYK37, JYK67 and JYK157 pages carry the same broad family figures: input power 0.12–200 kW, ratio 5.36–17,550 and output torque up to 50,000 N·m. These are catalogue-wide boundaries, repeated on differently sized housing pages; they are not simultaneous ratings for JYK37, JYK67 or any one build. The page should be used to choose a configuration conversation, not to infer a small housing can transmit the family maximum.

View JYK helical-bevel right-angle gearmotors →

Mounting choices change load paths

A foot-mounted reducer sends reaction loads through a base; a hollow-shaft unit and torque arm load the machine shaft and restraint differently. Zhongyi's listed variants require separate outline drawings and allowable overhung/axial loads. Confirm the driven-shaft diameter, key or shrink-fit arrangement, torque-arm anchor and service access before judging a quote by ratio and price.

Identity is independently visible; order ratings remain manufacturer-specific

The company's own site identifies the Lianshui legal entity and parking-drive focus. A listed transmission-components company's public prospectus independently names the same Huai’an Zhongyi entity among motor-sector counterparties and records its business scope. That disclosure is useful identity corroboration, not a test or certification of a JYK or JNAP configuration. Obtain the current type-specific documents for the actual offered drive.

03 / PURCHASE AND VALIDATE

A usable quotation must identify the complete drive and its test basis

Which information should the buyer send?

State whether the project is a parking lift or a horizontal/angled industrial drive; provide equipment drawing and duty cycle, output-speed and torque profile, motor supply, braking/holding requirement where relevant, service factor, external shaft loads, mounting arrangement, environment, expected lifetime, destination standard and quantity. For replacement, include the existing nameplate and all interface dimensions.

What must the proposed build prove?

Ask for a complete JNAP or JYK order code, motor and gearbox ratings at stated duty, permitted radial/axial loads, ratio and actual output speed, thermal limit, brake torque and release timing where fitted, orientation/lubrication rules, outline drawing and sample acceptance measurements. For parking equipment, separate the motor brake from any independent platform safety restraint and obtain the integrator's system-level validation.

Published motor range

1 series

Company information

Company name
Huai’an Zhongyi Electric Motor Co., Ltd.
Chinese registered name
淮安仲益电机有限公司
Region
Jiangsu, China
Record updated
2026-10-08
