MOTOR MANUFACTURER · Zhejiang, CHINA

Unite Motor

Zhejiang Unite publishes coded brushless wheel-hub motors and separate high-speed brushed DC drives. A wheel hub already includes a tire interface; a brushed motor may need its own reduction and final drive. Compare the intended vehicle load, voltage and mechanical interface at the exact code, not across family maximums.

LocationZhejiang, China
Published catalogue2 product series
Motor families2 represented

ZHEJIANG UNITE · SMALL VEHICLE DRIVE SELECTION

Zhejiang Unite drive motors: compare GF hub wheels and MY brushed drives

Explore the published range ↓

01 / BRUSHLESS WHEEL-HUB CODES

GF listings differ in voltage, rated speed and tire construction

GF075AQ: compact 24 V polyurethane wheel

The manufacturer lists GF075AQ at 24 V, 120 W rated output, 740 rpm, 1.4 N·m rated torque and 5.9 A rated current. Its page gives 125/135 mm polyurethane tire options and IP43 as the published enclosure level. The separately printed 210 W maximum power and 5.8 N·m maximum torque are peak figures, not continuous ratings or proof they occur at one operating point.

Confirm before ordering Confirm chosen tire diameter and tread, axle/fastener drawing, load per wheel, rolling speed, surface, temperature and controller. Ask for continuous and peak torque-speed curves at the actual wheel and duty.

GF075AQH and GF082AQH: 36 V rubber variants

GF075AQH is listed at 36 V, 150 W, 900 rpm and 1.6 N·m rated torque with a 145 mm rubber tire. GF082AQH is a distinct 36 V, 200 W, 1200 rpm listing with 1.6 N·m rated torque and a 135 mm rubber tire. Both print IP43, but their current, peak limits and geometry differ. A buyer should not order the higher-watt entry on power alone if the wheel envelope or desired ground speed differs.

Confirm before ordering State battery voltage range, desired road speed, slope and duty, tire size/material, braking method and controller feedback. Request drawings and the selected motor's current/thermal limits.

02 / A DIFFERENT MECHANICAL ARCHITECTURE

MY1020 brushed motors need a transmission and brush-service decision

The manufacturer's high-speed brushed category is distinct from its wheel-hub category. Select a motor, reduction path and controller as a package.

MY1020 / ZD108A1 is a multi-variant listing

The official card offers 350/500/750 W and 24/36/48/60 V options with rated speed and torque values listed in parallel, but it does not make every wattage and voltage combination one certified code. The stated applications include small electric vehicles and scooters. Ask which winding and rated point is quoted, then size the reduction and output shaft for the actual wheel load.

View MY1020 / ZD108A1 high-speed brushed DC motor →

MY1020ZXD has a stated 6:1 reduction

A separate page lists MY1020ZXD with 36/48 V, 350/450 W variants, rated motor speeds of 3100/3400 rpm and a 6:1 reduction, with light electric tricycle use named. It cannot be substituted by a bare MY1020 without checking output shaft geometry and whether the quoted speed is at motor or reducer output.

Controller and wear parts affect the usable package

State acceleration, regenerative or friction braking, peak current duration, reverse operation, ingress environment and expected brush-maintenance interval. Request a matching controller wiring diagram, thermal limits and spare brush availability for the exact motor.

03 / TURN A CATALOGUE CODE INTO A QUOTE

Give the supplier the vehicle's wheel load and operating cycle

What must happen at the ground contact?

Provide vehicle mass including payload, driven-wheel count, maximum gradient, target speed, acceleration time, tire diameter and surface. Distinguish continuous hill-climb duty from a short start or obstacle peak. Select the motor at a real torque-speed operating point, not by pairing a maximum torque with a maximum rpm from the page.

What is the electrical and mechanical interface?

List battery nominal/minimum/maximum voltage, current limit, controller type, feedback connector, brake type, mounting face, axle or gearbox output and cable routing. GF wheel hubs and brushed MY motors have different controller and final-drive needs.

What should be inspected before production?

Request a selected-model datasheet, tire or shaft drawing, controller pairing, continuous/peak thermal test, ingress instructions and a sample fitted to the vehicle. The maker's listed peak power, peak torque and rated speed should remain separate until tested at the intended operating condition.

04 / EXACT CODE, EXACT ENTITY

Model pages provide useful ratings; independent listings anchor the company name

Company-name cross-check

The current product site's footer names 浙江优奈特电机有限公司; its older About text also uses the related name 浙江尤奈特电机有限公司. A government enterprise record and a trade-show organizer independently list 浙江优奈特电机有限公司. This profile keeps the current published Chinese company name and does not transfer the older About page's group-scale or certification claims to a selected product.

Do not merge continuous and peak entries

GF075AQ, GF075AQH and GF082AQH have different coded rated voltage, speed and tire specifications. MY1020/ ZD108A1 is a multi-option listing rather than a single fixed rating. These distinctions come from the manufacturer's item pages; any offered variant still needs its own signed drawing and duty test.

Published motor range

2 series

Company information

Company name
Zhejiang Unite Motor Co., Ltd.
Chinese registered name
浙江优奈特电机有限公司
Region
Zhejiang, China
Record updated
2026-10-07
