YB3 explosion-proof motor

Manufacturer catalogue image · Series illustration

Explosion-proof motors

YB3 explosion-proof motor

Voltage
380 / 660 / 380–660 V
Duty
S1
Insulation
Class F
Frame Height
63–355 mm

Catalogue series · Exact configuration and availability confirmed by the manufacturer.

CATALOGUE OVERVIEW

About this motor series

Shenyin’s YB3 catalogue covers frames 63–355 for flameproof three-phase induction motors. It specifies 380 V, 660 V or 380/660 V at 50 Hz, with 60 Hz available by agreement. Rated duty is S1 and insulation class F. The stated installation altitude is at most 1000 m, with catalogue ambient conditions of −15 to +35 °C.

Mounting options depend on frame: the source lists B14/B34/V18 for 63–112 and a narrower B3/V1 selection for 315–355. Check the individual flange and shaft drawing before replacing a motor. The catalogue cites older explosion-protection standards; request a current certificate and exact delivered marking for the installation.

Model / series reference: YB3

Published specifications

Specifications describe a series range; confirm which ratings apply together to the quoted model.

Voltage
380 / 660 / 380–660 V
Duty
S1
Insulation
Class F
Frame Height
63–355 mm
Product Type
YB3 explosion-proof motor
Catalogue Scope
Manufacturer model or series
Rated Frequency
50 Hz; 60 Hz by agreement
Maximum Altitude
1000 m
Ambient Conditions
−15 to +35 °C
Power
Confirm configuration
Speed
Model dependent
Manufacturer
Shenyin Motor

Confirm mounting and shaft dimensions against the drawing for the quoted configuration.

Catalogue reference

Manufacturer
Shenyin Motor
Product reference
YB3 explosion-proof motor
Source reviewed
2026-09-21

Ask for the current datasheet and dimensioned drawing with your inquiry.

Selection guidance for Explosion-proof motors
  • Gas or dust environment
  • Site classification
  • Certificate and exact marking
  • Temperature and ambient range
  • Installation requirements
