MOTOR MANUFACTURER · Zhejiang, CHINA
TAIBANG MOTOR INDUSTRY GROUP CO., LTD.
Taibang Motor Industry Group in Yueqing publishes both compact geared motors and larger industrial gearmotor families under GPG. The useful first split is not a generic motor power figure: decide how the machine will control speed, how the output shaft must meet the load, and which mounting envelope is available.
TAIBANG GPG · GEARED DRIVE GUIDE
01 / CONTROL THE MOTION
The manufacturer's catalogue separates its 60 mm 2IK/2RK AC unit from its square-body 60 mm brushless DC unit. They are not interchangeable just because the mounting face is similar.
The official 60 mm 2IK/2RK page specifies class B insulation, an ambient range of -10 to +40°C and a motor-noise limit of 60 dB. Those are series-page conditions, not a torque or life guarantee for every gearbox combination.
Confirm before ordering Send supply voltage and frequency, target output speed, running hours, permissible envelope and the mating-machine drawing. Ask for the exact motor, ratio and gearbox part numbers.
View 2IK / 2RK 60 mm AC gear motor →Taibang lists 15 W and 25 W square-body brushless geared variants, class E insulation and a 0 to +40°C ambient range on the official series page. Its drawing downloads distinguish ratio groups; the controller and power supply still require configuration-specific confirmation.
Confirm before ordering State speed range, torque at the output, start-stop frequency, control interface and available DC supply; request the matched controller and dimensional drawing.
View 60 mm brushless DC gear motor →02 / FIT THE MACHINE
Taibang identifies RG as helical, FG as parallel-shaft helical and KG as helical-bevel. The family name narrows geometry; it does not settle the permitted radial load, ratio or exact motor frame.
The RG product page presents a helical hard-tooth gearmotor and downloadable catalogue material. Use it when an inline arrangement may fit, then check the selected casing, output shaft and mounting position against the machine drawing.
Confirm before ordering Request the selected ratio, service factor, output torque, permissible shaft load and mounting drawing rather than a series maximum.
View RG helical gearmotor series →FG is separately published as a parallel-shaft helical gearmotor. It offers a different arrangement for a drive that must sit alongside the output path; the actual offset and mounting dimensions depend on the specified build.
Confirm before ordering Provide available length, shaft height, output direction and load location; compare an FG drawing with the driven equipment.
View FG parallel-shaft helical gearmotor series →KG is the helical-bevel family, making it a candidate where a right-angle shaft path solves a machine layout problem. The product page does not make every ratio, input motor or mounting position available together.
Confirm before ordering Specify handedness, mounting position, shaft/hollow-bore details, shock loads and lubrication orientation on the requested configuration.
View KG helical-bevel gearmotor series →03 / BEFORE THE QUOTE
Give required output speed, continuous and peak torque, acceleration, reversal and duty cycle. Ask for the selected ratio, service factor and thermal limits for that exact motor-gearbox pairing.
A belt pulley, chain sprocket or offset coupling can add radial or axial loads that nominal motor power does not describe. Include the load's distance from the bearing and ask for permitted output-shaft loads.
Provide installation orientation, ambient conditions, enclosure needs, supply, controller or inverter details and cooling space. Taibang's own service guidance says to stay within the nameplate and catalogue limits and to confirm rotation direction before mechanical connection.
04 / WHAT THE RECORDS SHOW
The company's own English overview gives a Yueqing headquarters and a range spanning AC/DC geared motors, brushless drives and precision reducers. An independent trade-show organizer listed the Chinese legal company and an English rendering in its 2020 exhibitor list. That historical listing supports identity, not current output, certification or the suitability of a particular drive.
The manufacturer's company and contact pages identify Taibang Motor Industry Group Co., Ltd. at No. 216, Wei 16 Road, Yueqing Economic Development Zone. Its catalogue separates miniature motor lines from industrial gearmotor families.
The PTC ASIA organizer's exhibitor list, updated in October 2020, includes 台邦电机工业集团有限公司 and TAIBANG MOTOR INDUSTRIAL GROUP CO., LTD. It is a dated participation record, not third-party testing of any model.
Request the current catalogue and dimension drawing, gearmotor nameplate, performance curve, controller details where applicable and documentation tied to the quoted legal entity and model. A general company statement cannot substitute for these records.
05 / SEND A BUILDABLE REQUEST
Application, driven load, output rpm and torque profile, starts per hour, reversal, daily run time and target service life.
Available envelope, mounting orientation, required shaft path, mating drawing, pulley or coupling position and radial/axial load.
Site voltage and frequency or DC bus, speed-control method, controller/drive scope, ambient conditions, quantity, destination and the drawings and tests required before approval.
