Medium-voltage induction motors for compressors

Manufacturer catalogue image · Series illustration

AC induction motors

Medium-voltage induction motors for compressors

Power
500–40000 kW
Voltage
6,000–13,800 V
Poles
2, 4 or 6
Cooling
IC81W / IC86W water-cooled; IC611 / IC616 / IC666 air-cooled options

Catalogue series · Exact configuration and availability confirmed by the manufacturer.

CATALOGUE OVERVIEW

About this motor series

MCM lists an induction-motor range of 500–40,000 kW for compressed-air and industrial-gas machinery. Its catalogue separates that range from larger synchronous compressor machines; the synchronous figures are not included in this listing. Published options include two, four or six poles and a 6–13.8 kV voltage range.

Cooling and starting arrangements are project-specific. Provide the compressor torque-speed characteristic, train inertia, number of starts and network voltage-drop limits. Establish the cooling medium and allowable temperatures, bearing arrangement and foundation interfaces before final sizing. The catalogue range indicates engineering scope, not that every power, voltage and cooling combination is available as a standard product.

Model / series reference: Compressor induction range

Published specifications

Specifications describe a series range; confirm which ratings apply together to the quoted model.

Power
500–40000 kW
Voltage
6,000–13,800 V
Poles
2, 4 or 6
Cooling
IC81W / IC86W water-cooled; IC611 / IC616 / IC666 air-cooled options
Mounting
Horizontal IMB3 or project-specific
Frequency
50 Hz, 60 Hz or variable-frequency design
Power Basis
Induction motor family only
Speed
Model dependent

Confirm mounting and shaft dimensions against the drawing for the quoted configuration.

Catalogue reference

Manufacturer
MCM Electric Machinery
Product reference
Medium-voltage induction motors for compressors
Source reviewed
2026-09-21

Ask for the current datasheet and dimensioned drawing with your inquiry.

Selection guidance for AC induction motors
  • Rated output and duty
  • Voltage, phase and frequency
  • Pole count and rated speed
  • IEC frame and mounting
  • Efficiency class and enclosure
